PMC Premium Screen
Author：Webmaster Sources： Original site Date：2018-03-10 16:19:06 Hits：579 Parent：PMC Premium Screen
Detailed introduction
PMC Premium Screen is an excellent combination of the central liner (in line with the APIcasing&tubing) and filter sets (inner protective sleeve, inner end ring, square hole mesh, filter, outer protective cover, outer end ring).
Features
1、Protection sleeve with measuring hole, in the course of the operation can be a good protection sand filter layer, avoiding the well when the sand filter layer was punctured, scratched caused by the construction of sand control failure.
2、Its close packed structure and light weight makes it easily move through a long distance in a horizontal well.
3、Under the same condition, Its filtration area is 10 times as large as slotted
screen or wire-wrapped screen, so that the flow resistance is very low and production rate is high.
4、The filtration pores are stable and are of high deformation adaptive capacity, even the screen diameter deforms up to 40%, its sand control ability is still unchanged, so that it can satisfies the requirements in horizontal wells.
5、The filtration pores are distributed uniformly and are of high permeability and high anti-plugging ability. The PMC screen can extend screen service life by slowing down.
6、The outer protective sleeve with measuring hole can effectively protect the sand filter layer from the impact of high pressure oil and gas flow, so as to meet the requirements of large drainage of oil wells。
Features
1、Protection sleeve with measuring hole, in the course of the operation can be a good protection sand filter layer, avoiding the well when the sand filter layer was punctured, scratched caused by the construction of sand control failure.
2、Its close packed structure and light weight makes it easily move through a long distance in a horizontal well.
3、Under the same condition, Its filtration area is 10 times as large as slotted
screen or wire-wrapped screen, so that the flow resistance is very low and production rate is high.
4、The filtration pores are stable and are of high deformation adaptive capacity, even the screen diameter deforms up to 40%, its sand control ability is still unchanged, so that it can satisfies the requirements in horizontal wells.
5、The filtration pores are distributed uniformly and are of high permeability and high anti-plugging ability. The PMC screen can extend screen service life by slowing down.
6、The outer protective sleeve with measuring hole can effectively protect the sand filter layer from the impact of high pressure oil and gas flow, so as to meet the requirements of large drainage of oil wells。
7、High-quality anti-corrosion ability, high-strength compression capacity determine the long effective production life of sand control of PMC Premium Screen.
